Description
An LED Spreader Uplight smartly designed for mid to large size sailing yachts. The 6500 series has an oval foot mounting with a slant / hollow angle, ideal for swept back angle of modern spreaders. Suitable for 12V and 24V systems. The 16° light cone penetrates the night sky to illuminate high up the ship’s mast. The titanium anodized finish will look great season after season.
Features & Benefits:
- Mounts on top of spreader for uplight (mast) illumination
- Designed to fit curve & angle of modern spreaders
- Long lasting titanium anodized finish
- Extra long (60″) rugged duplex insulated cabling
- IP67 Waterproof Rating.
Name |
Description |
|---|---|
Housing Finish/Material |
Titanium/Anodized Aluminum |
Certifications & Compliance |
CE, ROHS |
Output Color |
Cool White |
Lifetime Hours |
40,000 hrs |
Halogen Equivalency |
50W |
Input Voltage |
10-30VDC |
Warranty |
2 years/1 year finish |
Dimensions |
2.55″ (l) x 1.73″ (w) x 1.22″ (h) |
Power Consumption |
3.6W |
Mounting Method |
M5 Screws or SS Rivets (not included) |
Luminous Flux |
500 lm |
Driver |
Integrated |
Install Location |
Top of Sailboat Spreader |
Correlated Color Temperature (CCT) |
4500K |
Color Rendering Index (CRI) |
>80 |
Approximate Ship Weight (lbs) |
1 |
| Weight | 1 lbs |
|---|---|
| Dimensions | 2.55 × 1.73 × 1.22 in |
