DHR60 All-Round Red LED, Base-Mount, Black – DH60070000

Description

24V (4.5W), 2NM, IP66, 360°

The DHR60 LED is the all-rounder in the DHR LED navigation light series.

Suitable for seagoing vessels from 20 to 50 meters (65′ to 164′) and inland navigation vessels from 20 meters and longer.

Due to the durable design and marine grade aluminium the DHR60 LED guarantees safety at sea in all weather conditions.

Leading brand LEDs and highest quality components assure the most robust and durable navigation light on the market.

Zero noise interference, excellent thermal management and 100.000 hour lifetime results in an exceptionally reliable product with minimal maintenance costs. The DHR60 LED also features a back-up LED/driver module built right in to the fixture and is completely user-serviceable with spare parts and repair kits readily available.

Meets UL1104 Standard.

DHR lights are CE-EMC tested and certified and will not interfere with VHF radios

Features

• For vessels up to 50meters in length
• Visibility from 2to 5 NM (depending on application)
• UV resistant matteblack, anodized aluminum housing
• Galvanically isolatedback-up LED module built in to fixture
• POM base to preventgalvanic corrosion
• Borosilicate glasslens
• Epoxy potted LED driverfor maximum protection
• User serviceable (partsand repair kit available)

Specifications

• Certifications & Compliance: IMO, Colreg 72, MED 96/98/EC, EN14744, UL1104 & USCG
• Output Color: Red
• Lifetime Hours: 50,000 hrs
• Class: I, (grounded)/III
• Input Voltage: 19-32VAC
• Dimensions: See dimensional drawing
• Warranty: 3 Years
• Power Consumption: 4.5W
• Lens Material: Boroscilicate well glass
• Ingress Protection: IP66
• Mounting Method: Base-mount
• Drive: Integrate (main & spare)
• Install Location: All-Round
• Electrical Protections: Transient Voltage, ESD Protection, Current Regulation

Click here for Dimensional Drawing
