F-23 LED Marine Courtesy Light – 10-30VDC White Red

Description

• F-23 LED Marine Courtesy Light – 10-30VDC White Red
• F-23 LED, 10-30VDC, White, Red, IP67
• F-23 is a small low profile surface-mount LED courtesy light offered in three different bezel finishes and several LED colors. User may position bezel for up/down or side to side wall wash effect. Applications include stairs, walkways, and architectural effects. F-23 may also be installed without the decorative bezel, providing a higher level illumination appropriate for small utility spaces, closets and lockers.

Features:

• Low profile, surface-mount design
• Tough polycarbonate housing
• Completely sealed for wet location mounting
• Extremely low power consumption
• Provides architectural wall-splash effect
• Excellent choice for stairs, walkways, or accent lighting

Specifications:

• Trim Ring (Bezel) Finish/Material: White Polycarbonate
• Housing Finish/Material: Polycarbonate
• Lens Material: Polycarbonate
• Trim Ring (Bezel) Dimensions: ø 1.41″ (36mm) x 0.35″ (9mm)
• Base Dimensions: ø 1.41″ (36mm) x 0.35″ (9mm)
• Integrated Switch: No
• Input Voltage: 10-30VDC
• Power Consumption: 0.5W
• Driver: Integrated
• Output Color: Red
• Luminous Flux: 15 lm
• Beam Angle: Wall wash
• Lifetime Hours: 35000
• Mounting Method: Screw (one)
• Ingress Protection: IP67
• Class: Class III, F-Rated
• Electrical Protections: Reverse Polarity, Transients, EMI
• Certifications & Compliance: CE, ROHS
• Manufacturer: Frensch
• Warranty: 3 years

ATTENTION CALIFORNIA RESIDENTS

WARNING: Cancer and Reproductive Harm

Click here for Dimensional Drawing
