Description
Introducing the Gen II Power Conditioner, designed for a 20A capacity, with a versatile 10.5-16VDC input range and a 12VDC to 14.4VDC adjustable output. This advanced power conditioning unit ensures optimal performance and stability for your electrical system. Elevate your power management with the Gen II Power Conditioner, offering precision control over voltage output in a robust and efficient design. Suitable for various applications, this conditioner provides reliable and adjustable power for your electronic devices. Trust in the Gen II Power Conditioner to enhance your electrical setup with its dynamic capabilities and customizable voltage output.
The InterVOLT SPCi Maxi Series Gen II power conditioners is a cutting edge product known for resolving many of the issues associated with DC power in vehicles and vessels. They are in fact a converter, stabilizer, isolator and regulator all built into a single innovative package. These devices feature galvanic isolation with no common connectivity between the input and output via positive or negative conductors. This means peace-of-mind when connecting sensitive and often expensive, high-end electronic equipment to the output. Other benefits include elimination of line interference, greater protection, better regulation and improved performance.
Typically Ships In 4-8 weeks
The GEN II unit has digital over analogue topology which allows the installer/operator to control and monitor various functions and provides valuable feedback on the status of the connected load.
The GEN II units are more compact due to multi-speed fan cooling and as a result no longer relies on convection for cooling.
Features:
- Unique operator interface for control and monitoring
- Galvanically isolated input to output – no common connectivity
- Handy charge mode for charging an auxiliary battery (2 stage)
- User adjustable output voltage from 12V to 14V (0.5V increments)
- Diagnostic indicator: stand by mode, load on, short circuit, temperature
- Remote operator control to turn unit on/off with signal current only
- Multi function alarm output for fault and pre-emptive warnings
- Temperature and speed controlled internal cooling fan (Vapo bearing)
- Compact design and can be mounted vertically or horizontally
- Heavy duty termination with separate, removable terminal cover
- High quality assembly featuring marine grade hardware
- Conformally coated printed circuit board assembly.
Specifications:
Name |
Description |
|---|---|
Housing Finish/Material |
Anodized 6063 aluminum, ABS/PC , stainless steel hardaware |
Certifications & Compliance |
CE-EMC, ROHS, Australian C-Tick |
Class |
B |
Input Voltage |
10.5-16VDC (down to 9V during operation) |
Dimensions |
9.10″ (230mm) x 1.17″ (110mm) x 2.17″ (55mm) |
Warranty |
2 Years |
Output voltage |
12.0-14.0VDC (adjustable in 0.5V increments) |
Ingress Protection |
IP40 |
Load Rating |
20A (continuous), Peak Load is 125% |
Mounting Method |
Screws (vertical or horizontal surface) |
Max Operating Temperature |
122° F (50° C) |
Standby Current |
85mA (nominal) |
Efficiency |
91% nominal (load dependent) |
Install Location |
Dry loaction, vertical or horizontal |
Electrical Protections |
Transients, overload/short circuit, over temperature, over voltgae, reverse polarity, and more… |
Approximate Ship Weight (lbs) |
3 |
| Weight | 3 lbs |
|---|---|
| Dimensions | 9.10 × 1.17 × 2.17 in |
