Description
Hydromatic I 4 Stage Control Board
(OBSOLETE) No Longer Available
The Hydromatic I is the classic, legacy control system for multi-stage marine chillers. It has been sold for over 20 years and is installed on hundreds of boats around the world. Hydromatic I has stood the test of time because of its simple and robust operation.
Features
- Integrated and configurable 115 or 240VAC/50-60Hz Logic Power Supply
- Separate Control Power Supply input available (24/115/230VAC) to power contactors and valves
- Supports up to 4 stages with individual compressor, electric heater, and reversing valve outputs
- Isolated triac outputs for all AC control outputs
- 8-Pin Display Interface
- High and Low Pressure Safety Switch Inputs for each stage
- Oil Pressure or Flow Switch Safety Inputs for each stage that can be use with individual Freezestats
- Separate Service (condenser) Temp Sensor Inputs for each stage
- Common Return and Supply Water Temp Sensor Inputs
Specifications/Notes
DIMENSIONS:
- 12.5 x 6.5
| Weight | 2 lbs |
|---|
