Description

• LED Power Supply: 90-305VAC to 24VDC, 600W, IP65
• Our highest capacity Power Supply (i.e. LED voltage converter), the HLG-600 Single Output Switching Power Supply is a high-performance dustproof and waterproof AC-to-DC LED power supply for loads up to 600W. With an aluminum case and fully potted silicone, HLG-600H features IP65 protection level, 5G anti-vibration capability, and industrial-level immunity against instantaneous surge up to 4kV. This model is equipped with the internal potentiometers enabling the output current and output voltage to be adjusted. These attributes make HLG-600H ideal for indoor/outdoor LED lighting applications that might be dusty, moist, or a vibrating harsh environment. model features a universal selectable AC input (90-305VAC) and adjustable DC output (20.4-25.2VDC) providing clean voltage-regulated DC power; ideal for sensitive electronics and LED lighting.

Features:

• Selectable AC input (90~305VAC)
• Adjustable voltage output (20.4~25.2V)
• Adjustable current output (12.5~25A)
• Shock & vibration resistant to 5Gs
• 95% efficiency rating
• Standby power consumption <0>
• Typical lifetime>62,000 hrs
• Full electrical protections (current, voltage, temperature)

Specifications:

• Housing Finish/Material: Aluminum
• Dimensions: 144mm x 48.5mm x 28mm
• Power Consumption: Stand by <0>
• Efficiency: 0.95
• Max Operating Temperature: +70°C
• Lifetime Hours:>62,000 hours
• Dimmer Compatibility: Non dimmable
• Mounting Method: Panel
• Install Location: Interior/Exterior
• Ingress Protection: IP65
• Class: I
• Electrical Protections: Over current, short circuit, over voltage, over temperature
• Certifications & Compliance: CE-EMC, UL, CSA, ENEC
• Manufacturer: Meanwell
• Warranty: 7 Years
