Description
LW415AN/1
Tigres, Anodized, 24V, 1500W, Lofrans
Item: LW415AN/1
Tigres, Anodized, 24V, 1500W
Typically Ships In 36 Days
Standard Equipment:
- Watertight Control Box
- Two (2) Footswitches
- Chainwheel
- Manual Override w/Handle.
Specifications:
Power Supply |
24V |
Motor Wattage |
1500W |
Power Rating (lbs) |
2400 |
Finish |
Anodized |
Approx. Amp Draw |
50-70 |
Max Retrieval Speed (ft./min.) |
80 |
Chain Size |
1/4″, 5/16″, 3/8″ |
Dimensions |
16.38″(Width), 13.75″(Height), 17.75″(Length) |
Rope Size |
1/2″ – 3/4″ (Rope Drum) |
Downloads
- Brochure LW415AN
- Dimensional Drawing LW415AN
| Weight | 62 lbs |
|---|---|
| Dimensions | 17.75 × 16.38 × 13.75 in |
