Description
- Lumishore Surface Mount Underwater Light – M-Series Supra SMX23, 48W
- 10-31VDC, Bronze, IP68
- Smaller, brighter and more efficient than any competing underwater light – period. At just 3.75″ diameter, these little guys can be fitted nearly anywhere on the hull. They are twice as bright and double the efficiency when tested against any competing light. Choose between bright white or brilliant blue LED. Intuitive controllers including new Lumi-Link MFD Integration with Garmin OneHelm
Features:
- Automatic synchronization – all lights, all modes, all colors
- Recommended for vessels up to 50′ (15M)
- Internal driver
- Wide 90° viewing angle
- Use on/off toggle for basic modes (color selection, fade, strobe)
- Use with Lumi-Switch/Hub for additional synchronizing features
- Wifi Control (via MFD) – iOS compatible
- Lumi-Link MFD Integration (Garmin OneHelm)
Specifications:
- Housing Finish/Material: Bronze/Glass Lens
- Lens Material: Toughened BK7 Borosilicate
- Base Dimenions: 3.75 inch (95mm) dia
- Dimensions: 3.75 inch (95mm) x 0.71 inch (18mm)
- Input Voltage: 10-31VDC
- Power Consumption: 48W
- Driver: Dual Channel Internal
- Output Color: Cool White/Blue
- Luminous Flux: 11,250 lm (5,000 fixture lm)
- Beam Angle: 110°
- Lifetime Hours: 50,000 hrs
- Mounting Method: 3 x A4 fasteners (supplied)
- Install Location: Tranzom, Hull-Sides
- Ingress Protection: IP68
- Electrical Protections: ATRB (automatic thermal rollback), surge, low voltage, soft start, reverse polarity, noise suppression
- Certifitcations & Compliance: CE, ROHS, ABS, RINA, DNV
- Manufacturer: Lumishore
- Warranty: 2 Years
ATTENTION CALIFORNIA RESIDENTS
WARNING: Cancer and Reproductive Harm
Click here for Dimensional Drawing
