Lumishore TIX1603-CCP Under Water Light – LM600338

Description

EOS Color-Change, 24VDC Only

Features

• Includes 1 meter of DMX cable assembly for quick connect to an existing TIX 802 Color Changing System
• Low profile, flush-fit design for transom, hull side, or bottom mounting
• Recommended for boats from 25-330ft (7-100M)
• 34,875 lumens (15,500 fixture lumens), 110dg beam angle
• 9 preset colors plus 6 user-defined selections
• Color scene, sweep, mix, cycle, & strobe modes
• Exclusive Sound to Light integration with on-board audio
• Wi-Fi Control with iPad/iPhone compatibility
• Toughened BK7 Borosilicate Lens
• Over voltage/current, reverse polarity, and thermal rollback protection

Specification

• Trim Ring (Bezel) Finish/Material: Marine grade aluminum-bronze
• Lens Material: Toughened BK7 Borosilicate
• Trim Ring (Bezel) Dimensions: 5.50″ (140mm) dia x 0.43″ (11mm) profile height
• Dimensions: 5.50″ (140mm) dia x 0.43″ (11mm) profile x 7.24″ (184mm) total shaft length (with grommet)
• Cut-Out Dimensions: 3.625″ (92mm)
• Load Rating: 6.5A (24V)
• Recessed Depth: 7.24″ (184mm) shaft length
• Dimensions: 2.56″ (65mm) x 4″ (100mm)
• Input Voltage: 20-31VDC
• Power Consumption: 156W max (per fixture)
• Driver: Integrated (interchangeable)
• Luminous Flux: 34,875 lms (15,500 fixture lms)
• Output Color: RGBW
• Beam Angle: 110°
• Lifetime Hours: 50,000 hrs
• Mounting Method: Thru-hull, backing plate, bonding required
• Install Location: Transom, Bottom, Hull-Side
• Ingress Protection: IP68
• Class: III
• Electrical Protections: ATRB (automatic thermal rollback), surge, low voltage, soft start, reverse polarity, noise suppression
• Certifications & Compliance: CE, ROHS, ABS
• Manufacturer: Lumishore
• Warranty: 3 Years
