Ventura-rs Powerled, 10-30vdc, Brushed Steel 2x3w Highflux Led, Warm White Square Bezel – Ilim30472

Description

Ventura-rs Powerled, 10-30vdc, Brushed Steel 2x3w Highflux Led, Warm White Square Bezel – Ilim30472

The Ventura-RS PowerLED recessed spot is Imtra’s most powerful PowerLED spot. Its lumen output matches most 20W halogen spots of similar size. Its special duo-chip technology with proprietary drive electronics and carefully designed reflector results in a cleaner and smoother aperture appearance (than halogen), resulting in light which is free of annoying striations or distracting hot spots. Imtra’s carefully designed thermal management system results in maximum life with minimal lumens depreciation over its working life (approx. 50,000 hrs). Like all of Imtra PowerLED spots & fixtures, the Ventura is 100% dimmable when used with Imtra’s power-saving PWM momentary digital dimmer. The Ventura-RS model features a modified square bezel design for those seeking a truly unique style. Made in the USA and confidently offered with a 5 year warranty!

Features

• Ultra flat stainless steel bezel
• High lumen output
• Solid-state circuitry
• Minimal power consumption
• Completely sealed LED sub-assembly
• Integrated drive electronics (no external driver)
• PWM dimmer interface

Specifications:

• Certifications & Compliance: CE-EMC, CSA C22.2#250.0
• Output Color: Warm White
• Lifetime Hours: 50,000 hrs (L70)
• Class: Class III
• Dimmer Compatibility: See ILIM80120
• Dimmer Control Interface: 1P/1T NO or 1P/2T NO/NO Momentary Push Button Switch
• Cut-out Dimensions: 2.63″ (67mm)
• Halogen Equivalency: 25W
• Manufacturers Part No: ILIM30472
• Input Voltage: 10-30VDC
• Warranty: 5 Years / 1 Year Finish
• Finish: Brushed Stainless Steel
• Lens Material: Frosted glass
• Recessed Depth: 1.14″ (29mm)
• Max Wattage: 4.7W
• Dimming Range: 10% – 100%
• Mounting Method: Springs
• Luminous Flux: use 183 lm for warm white models, 258 lm for cool white, and 220 lm for neutral white
• Profile: Flat
• Driver: Integrated
• Electrical Protections: Reverse Polarity, 200V Spike Protection, Transient Protection
• Correlated Color Temperature (CCT): 2800K
• Color Rendering Index (CRI): 83
• Approximate Ship Weight (lbs): 1
